Form | Integrated DC amplifier | ||
<Tuner, the Aux->SP out overall characteristic> | |||
Effective output (20Hz - 20kHz) | 120W+120W (4 ohms, 0.007%) | ||
120W+120W (8 ohms, 0.003%) | |||
THD | 0.003% (Output-power-3dB, 20Hz - 20kHz) | ||
Power bandwidth (THD 0.02%) | 5Hz - 100kHz | ||
TIM | Incapable measurement | ||
Remains noise (straight DC) | 0.7mV | ||
Dumping factor (8ohms) | 80 | ||
Load impedance | main or remote: 4ohms - 16ohms | ||
main and remote: 8ohms - 16ohms | |||
<Other properties> | |||
Input sensitivity/impedance | Phono man month: 1.0mV, 2.5mV / 47kohm | ||
Phono MC: 100 microvolts/100 ohm, 250 microvolts/220 ohms | |||
Tuner, Aux, Tape:150mV /, 33kohm | |||
Phono maximum permissible input | MM:170mV(2.5mV) | ||
(1kHz, RMS, THD 0.01%) | MC:17mV (250 microvolts) | ||
THD | Phono man month->Rec out: 0.0005% (1kHz, output 5V) | ||
Frequency characteristic | Tuner, Aux, and Tape:20Hz-20kHz+0 -0.2 dB | ||
0.5Hz-170kHz+0 -3 dB | |||
SN ratio | Phono man month: 88dB (2.5mV input) | ||
Phono MC: 71dB (250-microvolt input) | |||
Tuner, AUx, Tape: 103dB | |||
Tone control | Super Bass: -0dB-+10dB (30Hz) | ||
Bass: ±7dB (100Hz) | |||
Treble: ±10dB (20kHz) | |||
Turnover frequency | Super Bass: 75Hz, 150Hz (12 dB/oct) | ||
Bass:500Hz | |||
Treble:2kHz | |||
Light filter | High: 7kHz, -6 dB/oct. | ||
Subsonic: 20Hz-12dB / oct | |||
Loudness control | 7dB (50Hz, Volume-30dB) | ||
Preamplifier part Output voltage (Rec out) | 150mV | ||
<Synthesis> | |||
Power source | AC100V, 50Hz/60Hz | ||
Power consumption | 205W | ||
Dimensions | Width 430x height 120x depth of 350mm | ||
Weight | 14.7kg |
